Description
MODEL: Airhorse AHD20A (Price is Negotiable)
Airhorse AHD20A is a rotary screw air compressor with motor direct driven method. Features with double Screw with low noise, Super Silenced Enclosure Elegant compact design.
FEATURES
- Double Screw with low noise, Super Silenced Enclosure
- Elegant compact design. Fully open access door to inner parts for easy service.
- Machine was CE and UL certificated ,Machines under ISO9001 quality management standard system.
- Progressive Adaptive Control (PAC) Protection
- Continuously monitors key operating parameters and adapts to prevent unexpected downtime
- V-Shield Technology
- Provides a totally integrated, leak-free design
- Sequential Cooling System
- Significantly improves efficiency, serviceability and noise level
SPECIFICATIONS
| Free Air Deliver / Discharge Pressure | 2.3m³/min / 8Bar |
| Compression Stage | Singe Stage |
| Ambient Temperature | -5°C to 45°C |
| Cooling Mode | Air Cooling |
| Discharge Temperature | Ambient Temperature 15°C |
| Lubricant | 10 L |
| Noise Level | 64 dBA |
| Drive Method | Direct Driven |
| Electricity | 415V / 3phase/ 50Hz |
| Motor Power | 15kW / 20HP |
| Starting Method | Y Starter (Star Delta) |
| Dimensions (L x W x H) | 940 x 800 x 1075mm |
| Weight | 325kg |
| Air Outlet Diameter | 3/4″ |
