HCP 80AFP42.2: Submersible Sewage Pump, Power 2200W, 3Ø, Discharge 3″, Head 16.5m, Flow 1200L/min, 58kg


Available on backorder


Model: 80AFP42.2

HCP 80AFP42.2 (made in Taiwan) is a submersible pump for sewage water.

  • 3 phase


  • International standard design : cable, auto-cut, dry-motor, silicon carbide mechanical seal, high grade cast iron offering highest quality and performance.
  • P/U/E multiple impeller designs to handle sewage solids and/or fibrous substances.
  • Superior abrasion resistant mechanical seal manufactured with silicon carbide to ensure the best seal effect.
  • Oil lip seal mounted outside of seal chamber stops solids gathering around seal faces.
  • Full range offering low to high head and flow capabilities, with compact and easy installation.
  • Available with Guide Rail System, which allows automatic remote connection and disconnection without entering the pit.


  • Drainage of waste water from the attenuation tank, purifying tank and sewage tank in water treatment plant.
  • Drainage of waste water containing fibrous additives from leather factory, dyeing factory and food processing factory.
  • Sewage management, accumulated water, septic tank, stock farm.


Power 3 HP (2200 watts)
Discharge 3″ (80mm)
Start Method Direct
Efficient / Maximum Head 10 / 16.5 meters
Efficient / Maximum Flow Rate 600 / 1200 L/min
Solid Passage 50mm
Weight 58 kg

Additional information

Weight 58 kg

Power Source
