Description
MODEL: LEO 4XR6/34-4 (Price is Negotiable)
LEO 4XR6/34-4 is a 4″ diameter deep well (borehole pump) with stainless steel body & poly impeller. Designed for water supply from wells or reservoirs.
Applications
- For water supply from wells or reservoirs.
- For domestic use. Civil and industrial applications.
- For garden use and irrigation.
Operating Conditions
- Maximum fluid temperature up to 35℃
- Maximum sand content: 0.25%
- Maximum immersion: 150m
Motor & Pump
- Rewindable motor
- Equip with start control box
- Enclosures class: IP68
- Insulation class F
SPECIFICATIONS
| POWER | 4kW, 5.5HP |
| VOLTAGE | 3 phase |
| OUTLET | 2” |
| FLOW RATE | 20~140 L/min |
| HEAD RANGE | 242~67 meters |
| PACKING DIMENSIONS (Diameter x H) | 100mm x 2154mm |
| WEIGHT | 33.8 kg |
