Description
Model: LEO LRP32-80/180 (Price is Negotiable)
LEO LRP32-80/180 is a circulation pump for hot water up to 110°C. Designed for pressure boosting of hot water in family, water circulation for central & district heating system
Applications
- It is widely used for heating ventilating and air conditioning (HVAC) circulation, pressure boosting of hot water in family.
- homes powered by solar energy
- industrial auxiliary equipment cold and hot water circulation and so forth
- Water circulation for the central and district heating system
- Domestic hot water circulation
Pump
- Brass or anti-rust cast iron pump body
- Noryl impeller with heat resistance up to 150°C
- 95% alumina ceramic shaft
- Liquid temperature: 2°C – 110°C
Motor
- Insulation class: H
- Enclosures class: IP44
- 99% alumina ceramic bearing
- Copper winding
- Three speed motor
Specifications
| Size Discharge | 1½”x1½” |
| Power | 0.27kW / 220V / 50Hz |
| Flow Rate | 166/100/60L/min |
| Head | 7.3/6.7/5.4 meters |
| Manometric Suction Lift | N/A |
| Liquid Temperature | Maximum +110°C |
| Environment Temperature | Max. +50°C |
