Description
MODEL: Pentax CAB200/01
Pentax CAB200/01 is a self-priming centrifugal pump for the water supply (also mixed with gas) of small and medium domestic and civil installations; when connected to autoclave tanks it provides an automatic pressurisation system.
SPECIFICATIONS
| Size Discharge |
1½″ x 1″ |
| Power |
1500 W / 240V |
| Flow Rate |
20 ~ 110 L/min |
| Head |
59.5 ~ 34 meters |
| Manometric Suction Lift |
Max. 9 meters |
| Dimensions (L x W x H) |
626 x 220 x 240mm |
| Weight |
33kg |
CONSTRUCTION FEATURES
| Pump body |
cast iron |
| Motor bracket |
cast iron |
| Impeller |
brass |
| Seal |
ceramic-graphite-NBR |
| Pump shaft end |
steel AISI 303 hydraulic side |
| Ambient temperature |
0 – 50 °C |
| Pump body gasket |
max 8 bar |
MOTOR
| 2 poles induction motor |
3~ 230/400V-50Hz
1~ 230V-50Hz (with thermal protection) |
| Insulation class |
F |
| Protection degree |
IPX4 |
