Description
Model: Pumpman TST80-160/220 (Price is Negotiable)
Pumpman TST80-160/220 single impeller centrifugal pump featuring axial intake and radial discharge. Used for: water supply, cleaning sets, pressure boosting, firefighting sets, irrigation, industrial applications, water circulation in climatisation sets, agricultural applications.
Applications
- Circulation and transfer of clean, chemically non-aggressive water and other liquids
- Water supply & irrigation
- Water circulation in air conditioning systems
- Fire fighting system
Operating Conditions
- Delivery: up to 220 m3/h
- Head: up to 95 m
- Suction: up to 7m
- Liquid temperature: Standard -10°C to 90°C
- Maximum operating pressure: 10 bar (PN10)
- Allowed motor to operate continuously for a long time: S1
Structural Features
- EN733 standard centrifugal pump casing dimensions
- Cast iron pump body
- Flange connection
- Cast iron impeller
- Motor insulation class F, protection class IP55
Specifications
| Size Discharge | 4″x3″ |
| Power | 30HP / 415V / 50Hz |
| Flow Rate | 1000~3500L/min |
| Head | 43.5~28.4 meters |
| Manometric Suction Lift | Max. 7 meters |
| Liquid Temperature | Maximum +90°C |
| Environment Temperature | Max. +40°C |
