REX N100A: Pipe Threading Machine, Threading Capacity: 1/2″ to 4″, Motor 1000W, Spindle 13 – 43rpm, 123kg


Model: N100A

REX N100A is a pipe threading machine with threading capacity from 1/2″ to 4″.


  • Less than 100 sec to make a perfect 4″ pipe taper thread. Less than 20 sec for a 1″ pipe taper thread.
  • Uni-auto die head for ½ – 2 ” pipe. Dies are compatible with NP50A/NP80A manual die heads and Uni-auto die heads.
  • Profiling die head for 2½ – 4″ pipe. REX original profiling system enables precise, straight tapers, with 20 mm dies performing at higher speed and requiring less power consumption.
  • Quick, adjustable cutter.
  • Quiet, maintenance-free condenser motor.
  • Built-in tool box is convenient for on-site work.
  • Large-capacity scrap catcher.
  • Threading size, thread length, and microfine adjustment of thread diameter can all be adjusted easily.
  • Compact and lightweight for its class (123kg), it can be set up by just two people.


Threading Capacity 1/2″ – 4″
Motor Voltage 220V 50Hz
Motor Power Input: 1000 W
Output: 750 W
Rotation Speed (Unloaded) a) 13 rpm
b) 24rpm
c) 43rpm
Dimensions (L x W x H) 873mm x 635mm x 558mm
Weight 123 kg

Accessories Included

  • Cutting oil (50W-R) 4 Liters.
  • Hex key wrench
  • BSPT Dies 1/2″-3/4″ x 1set
  • BSPT Dies 1″-2″ x 1 set
  • Die Head 2-1/2″ – 4″ x 1unit

Additional information

Weight 130 kg

Power Source
