Description
Model: M100
SAER M100 self priming water pump.
- 1 phase
- Made in Italy
Descriptions
- The deep well self prime pumps have the capacity of lifting water to a maximum of 45 meters.
- The pump is located on the surface with the ejector immersed into the well.
- The delivery of the fluid generated by the impeller is conveyed only in part to the outlet, the remaining delivery is recycled by means of a piping through the ‘VENTURI’ system connected to the suction chamber which gives the necessary depression of the suction of the fluid where the ejector is immersed.
- The fluid sucked by the ejector gets mixed in the ‘VENTURI’ diffuser with the recycling fluid coming from the pump body and consequently the pressure increases, whereas the pressure of the recycling fluids goes up and it gets sucked by the pump by means of piping.
Applications
- Water supply to remote dwellings i.e. farmhouses.
- General water supply
- Pressurisation of water by using pressure vessels (autoclaves) horticultural irrigation
- Mist irrigation, Dairy, farm also industrial applications.
Application Limit
- Temperature of the liquid to +50 °C
- Ambient Temperature da -15 °C to +40 °C
- Manometric suction lift up to 9 m (HS)
- Max. working pressure 11 bar
Installations
- Upon installation always prime the pump body first before start up. Pump must be installed with the motor shaft in the horizontal position.
Specifications
| Size Discharge | 1¼”x1″ |
| Power | 750 W / Single Phase |
| Flow Rate | 1.67 ~ 24.6 L/min |
| Head | 54 ~ 33 meters |
| Manometric Suction Lift | Max. 9 meters |
| Liquid Temperature | Max. +50°C |
| Environment Temperature | Max. +40°C |
| Dimensions (L x W x H) | 360mm x 180mm x 207mm |
| Weight | 16.3 kg |
Accessories Included
- 4″ Immersed ejector
- Without cable
- Carton box
