Description
Model: Bosch GRL360HV
Bosch GRL360HV is a rotational laser for horizontal and vertical application with manual dual slope.
Accessories Included
-
Receiver bracket RB 30Order number: 2 610 A14 830
-
Universal mount WM 4 ProfessionalOrder number: 0 601 092 400
-
2 x 1.5 V LR20 battery (D)
-
Laser receiver LR 30 Professional
-
Laser viewing glasses, red, BL-GLASS (spare part number 1 608 M00 05B)
-
Laser targetOrder number: 1 608 M00 70B
-
1 x 9 V block battery (6LR61)
Features
- Versatile – Horizontal and vertical manual dual slope function enable change in grade in two-axis application
- Flexible – Variable-speed and Scan-angle selection allow optimum usability at different lighting conditions
- Robust – IP 56 rated to protect against dust and water for tough jobsite conditions, with shock-warning function to alert error due to vibration
Specifications
| Laser diode | 630 – 650 nm, < 5mW |
| Operating temperature | -10 – 50 °C |
| Storage temperature | -20 – 70 °C |
| Laser class | 3R |
| Working range, value | 60 m |
| Working range with receiver | 350 m (diameter) |
| Accuracy | ± 1.5 mm at 30m horizontal ± 3.0 mm at 30m vertical |
| Self-levelling range | ± 5° (8%) |
| Levelling time | 30 s |
| Dust and splash protection | IP 56 |
| Rotation speed | 0/150/300/600 min-¹ |
| Power supply | 2 x 1.5 V LR20 (D) |
| Operating time (max.) | 30 h |
| Weight, approx. | 1.8 kg |
| Colour of laser line | red |
| Color of plumb points | red |
