Description
Model: Mello CUT100
Mello CUT100 inverter air plasma cutting machine with IGBT technology.
It is portable enough to be carried to any job site. Connect to air compressor, grab the torch and start cutting right away.
Features
- Rate input power capacity: 17.8kVA
- Current Range: 30-100Amp
- Max. cutting thickness : 40mm
Specifications
| ITEM \ MODEL | UNIT | CUT 100 |
| Input Power Voltage / Freq. | V/Hz | AC415V 50/60 |
| Rate Input Power Capacity | KVA | 17.8 |
| Rated Input Current | A | 39.9 |
| No-Load Voltage | V | 315 |
| Current Range | A | 30-100 |
| Rated Output Voltage | V | 120 |
| Duty Cycle (25°c) | % | 60 |
| Efficiency | % | 85 |
| Power Factor (cos Φ) | 0.93 | |
| Insulation Class | B | |
| Protection Class | IP23 | |
| Arc-Starting | No-contact | |
| Air flow | m3/min | 0.36 |
| Max. Cutting Thickness | mm | 40 |
| Weight (G.W / N.W) | kg | 29.6 / 25 |
| Size (L x W x H) (CTN) | mm | 590 x 380 x 495 |
| Accessories | 1. 4 core power cable 3M. 2. Front Panel with KDP50 socket. 3. 300A Earth clamp with 3M 25mm² welding cable & KDP50 plug. 4. P80 Plasma Torch 5M. 5. 3M Air hose 2pcs hose clip. 6. Air Regulator. |
