Description
Model: CMK
SAER CMK is a high flow close coupled centrifugal water pump.
- Single Phase
- Made in Italy
Descriptions
- Single impeller close coupled centrifugal pump is fitted with the overhang impeller directly splined on the motor shaft.
- The liquid pumped is conveyed into the spiral shaped volute of the pump body, transforming the kinetic energy into dynamic pressure energy.
- Pressure and flow is achieved with minimum loss by means of the hydrodynamic closed impeller design.
Applications
- Industrial water supply
- Pressurised water using pressure vessels
- Horticultural & agricultural irrigation
- Civil and domestic water transfer
- Boiler & Chiller
- Refrigeration
Application Limit
- Temperature of the liquid to +70 °C
- Ambient Temperature da -15 °C to +40 °C
- Manometric suction lift up to 8 m (HS)
- Max. working pressure 6 bar
Installations
- Upon installation always prime the pump body before first start up.
- Can be installed with the motor shaft in either vertical or horizontal position.
- In the event of vertical installations, the motor must always be positioned above the pump body.
Specifications
| Size Discharge | 2½”x2½” |
| Power | 1500 W / Single Phase |
| Flow Rate | 300 ~ 750 L/min |
| Head | 12 ~ 3 meters |
| Manometric Suction Lift | Max. 8 meters |
| Liquid Temperature | Max. +70°C |
| Environment Temperature | Max. +40°C |
| Dimensions (L x W x H) | 372mm x 152mm x 225mm |
| Weight | 21.2 kg |
Accessories Included
- Without cable
- Carton box
